PE100 polyethylene (PE) pipe for water supply

outside diameter

SDR26

SDR21

SDR17

SDR13.6

SDR11

SDR9

SDR7.4

0.6MPA

0.8 MPA

1.0 MPA

1.25 MPA

1.6 MPA

2.0 MPA

2.5 MPA

Nominal Wall Thickness

Nominal Wall Thickness

Nominal Wall Thickness

Nominal Wall Thickness

Nominal Wall Thickness

Nominal Wall Thickness

Nominal Wall Thickness

20

2

2.3

3

25

2

2.3

3

3.5

32

2.4

3

3.6

4.4

40

3

3.7

4.5

5.5

50

3

3.7

4.6

5.6

6.9

63

3.8

4.7

5.8

7.1

8.6

75

4.5

5.6

6.8

8.4

10.3

90

4.3

5.4

6.7

8.2

10.1

12.3

110

4.2

5.3

6.6

8.1

10

12.3

15.1

125

4.8

6

7.4

9.2

11.4

14

17.1

140

5.4

6.7

8.3

10.3

12.7

15.7

19.2

160

6.2

7.7

9.5

11.8

14.6

17.9

21.9

180

6.9

8.6

10.7

13.3

16.4

20.1

24.6

200

7.7

9.6

11.9

14.7

18.2

22.4

27.4

225

8.6

10.8

13.4

16.6

20.5

25.2

30.8

250

9.6

11.9

14.8

18.4

22.7

27.9

34.2

280

10.7

13.4

16.6

20.6

25.4

31.3

38.3

315

12.1

15

18.7

23.2

28.6

35.2

43.1

355

13.6

16.9

21.1

26.1

32.2

39.7

48.5

400

15.3

19.1

23.7

29.4

36.3

44.7

54.7

450

17.2

21.5

26.7

33.1

40.9

50.3

61.5

500

19.1

23.9

29.7

36.8

45.4

55.8

560

21.4

26.7

33.2

41.2

50.8

62.5

630

24.1

30

37.4

46.3

57.2

70.3

710

27.2

33.9

42.1

52.2

64.5

79.3

800

30.6

38.1

47.4

58.8

72.6

89.3

900

34.4

42.9

53.3

66.2

81.7

1000

38.2

47.7

59.3

72.5

90.9

1200

45.9

57.2

70.6

88.2

109.1

1400

53.5

66.7

82.4

102.9

1600

61.2

76.2

94.1

117.6

PE pipes are widely used in our daily lives and have the following advantages:

⑴ Reliable connection: The polyethylene pipeline system is connected by electric melting method, and the strength of the joint is higher than that of the pipeline body.
⑵ Good low-temperature impact resistance: Polyethylene has an extremely low low-temperature brittleness temperature and can be safely used within the temperature range of -60-60 ℃. During winter construction, due to the good impact resistance of the materials, there will be no occurrence of pipe brittleness.
⑶ Good stress cracking resistance: HDPE has low notch sensitivity, high shear strength, excellent scratch resistance, and outstanding environmental stress cracking resistance.
⑷ Good chemical corrosion resistance: HDPE pipes can withstand corrosion from various chemical media, and the chemicals present in the soil will not cause any degradation effect on the pipes. Polyethylene is an electrical insulator, therefore it does not undergo decay, rusting, or electrochemical corrosion; In addition, it does not promote the growth of algae, bacteria, or fungi.
⑸ Aging resistance and long service life: Polyethylene pipes containing 2-2.5% uniformly distributed carbon black can be stored outdoors or used for 50 years without damage from ultraviolet radiation.

timg

HDPE塑料管

HDPE管

4270491959_548501921

工厂图

工厂图二

质量体系

质量证书

我们的客户

Standing tall in the pipeline industry for 18 years,Zhongsheng speaks with strength

The Zhongsheng production base covers an area of 80 acres and has a mature production team of over 100 people;

Zhongsheng has a registered capital of 10.418 million yuan and an annual output of 2000 tons. Its products are exported to domestic markets as well as Southeast Asian countries such as Cambodia and Yugoslavia.

Excellent quality,100% compliance with national quality inspection standards

Using new raw materials from Sinopec (highest grade 100 polyethylene particles) to ensure material safety and non toxicity;

6 production quality inspection standards, professional testing, product must be inspected before leaving the factory;

The product has reliable performance and a service life of up to 70 years.

Zhongsheng Plastic Industry has its own production workshop,Better price

Zhongsheng Plastic Industry has over 10 advanced extrusion/injection molding machines, professional personnel, efficient cooperation, and benefits for customers;

Zhongsheng has established long-term cooperative relationships with numerous material suppliers, eliminating intermediate links and offering better prices.

Comprehensive value-added services,Let you worry free

Pre sales: Free on-site inspection, design proposal, and sample delivery service;

In sales: Professional project managers provide one-on-one service, strict quality control management, dedicated personnel coordinate and communicate throughout the process to ensure timely delivery;

After sales: Professional technicians come to install and provide guidance services, and attentive customer service follows up and maintains at all times.
