XTM35 series DIN rail mounted single-phase electronic energy meter series. Our company adopts microelectronics technology and imported large-scale integrated circuits, and applies advanced digital sampling

Developed advanced technologies such as processing techniques and SMT processes. It has independent intellectual property. Its performance fully complies with GB/T17215.321-2008 (Level 1 and

The relevant technical requirements for a 2-level static AC active energy meter are that it can accurately and directly measure the active energy of loads in a 50Hz or 60Hz single-phase AC power grid

The consumption of this meter can be measured by a meter and displayed on an LCD for active power. He has the following characteristics: good reliability, small size, light weight, beautiful appearance, convenient installation

Install and wait. At present, this form has obtained the patent certificate issued by the China National Intellectual Property Administration of China. Patent number 2012 3 0473501.3, patents from other countries are currently under review.

XTM35 series electric energy meter: Installed on a 35mm standard rail, in compliance with DIN EN50022 standard.

XTM35 series electric energy meter: Two pole width (module 17.5mm), in compliance with DIN43880 standard.

XTM35 series electric energy meter: Standard configuration includes a 5+1-bit (99999.1) meter or a 5+1-bit LCD (99999.1) display.

XTM35 series electric energy meter: Standard configuration with passive electric pulse output (polarity), easy to connect with various AMR systems, compliant with IEC 62053-21 and DIN

43864 standard.

XTM35 series electric energy meter: dual color LED indicator light indicates power status (green) and electric energy pulse signal (red).

XTM35 series electric energy meter: automatically detects the flow direction of load current and indicates it (only when the red electric energy pulse signal is working, if there is no green indicator power supply,

This means that the flow direction of the load current is opposite.

XTM35 series electric energy meter: can measure active power, voltage, current, power, power factor, frequency and other data.

XTM35 series electric energy meter: measures single-phase two-wire active energy consumption in a single direction. It is independent of the direction of load current flow. Its performance fully complies with GB standards/

T17215.321-2008 standard.

XTM35 series electric energy meter: direct connection, standard configuration S-type wiring.

XTM35 series electric energy meter: It has an extended terminal cover and a short terminal cover to protect electrical safety.

XTM35SQ XTM35SQ XTM35SC XTM35SD
