Workswell high frame rate dual camera (HD+HD thermal infrared)
WIRISPro airborne high frame rate dual camera imaging system, with a frame rate of 30Hz or 9Hz optional, a thermal infrared image super-resolution mod
Product details
WIRIS ProAirborne high frame rate dual camera imaging system
WIRIS Pro airborne high frame rate dual camera imaging system, with optional frame rates of 30Hz or 9Hz, and a thermal infrared image super-resolution mode of up to 1266x1010 pixels (resolution 1.3Mpx),The temperature sensitivity is 50mK, and the advanced version is 30mK. It can measure temperatures up to+150 degrees Celsius℃, multiple field of view angle lenses to choose from, real-time preview during operation, 14 times continuous digits; The digital camera has an imaging resolution of up to 1920x1080 pixels and is equipped with anti shake function.
The WIRIS Pro thermal infrared imaging device has extremely rich peripheral hardware interfaces, supporting CAN and S.BUS bus protocols, and can perform various trigger measurements such as PWM and TTL. It has an HDMI high-definition video interface, which can easily integrate the system and remotely view and analyze data in real-time. Built in 128GB or 256GB solid-state storage space, batch processing can be performed using WIRIS software.
High measurement accuracy, high resolution, and high thermal sensitivity
Rich interfaces, 10x magnification RGB camera
WIFI transmission of video streams, images, and commands; Excellent software functionality
128/256GB SSD、 External USB flash drive or Micro SD card, SDK development
Technical Parameter
WIRIS ProAirborne high frame rate dual camera thermal infrared imager | |
IR image resolution |
640 x 512/1266 x 1010 pixels |
Measuring range |
-25℃~+150℃， -40℃~+550℃Or+50℃~1000℃、 +400℃~1500℃optional |
Temperature sensitivity |
0.05℃(50mK)； zero point zero three℃(30mK) optional |
Temperature measurement accuracy |
± 2% or ± 2℃(Actual measured value ＜ ± 1)℃） |
Frame rate |
9 or 30Hz optional |
spectral range |
7.5~13.5μm |
Lens specifications |
18 °, 32 °, 45 °, 69 ° are optional and can be replaced by oneself |
Digital zoom |
1-14x sustainable zoom |
digital camera | |
spatial resolution |
1920x1080 pixels (FHD) |
Perspective/focal length |
6.9 °~58.2 °/focal length 33.0mm~3.3mm |
Zoom |
10x optical zoom with anti shake function |
Zoom |
Full HD 10x optical zoom with anti vibration compensation function |
Other functions | |
CAN bus protocol |
Compatible with DJI M600 and A3 controllers |
SBus bus protocol |
Supports 18 channel signals |
trigger |
PWM, S.Bus or external TTL trigger |
Function options |
Temperature range setting, alarm mode (isotherm), max large/min small/center point analysis, scaling, image capture, video capture, mode, etc |
Memory |
Internal high-speed SSD 128GB or 256GB; External SD card slot, USB 2.0 can be connected to an external USB flash drive (camera control and video streaming are only optional upon request) |
GPS Information |
When connected to an external GPS, GPS data can be directly recorded in images or videos |
Hot/Cold Spot Detection |
Automatic hot/cold spot detection with temperature value attached |
emissivity correction |
Calibrate directly in WIRIS or in software |
Other corrections |
Reflection temperature and atmospheric temperature correction |
power supply |
9~36VDC，12W |
Dimension |
83mm x 85mm x 68mm,<> |
operation temperature |
-20℃~+55℃ |
Rich software features
