The price of customized chlorine dioxide generator

The chlorine dioxide generator consists of a feeding system, a reaction system, a temperature control system, an absorption system, a safety system, a residual liquid automatic control system, and an electrical control system; Assembled structure, equipment is produced and manufactured according to standards. The shell of the reaction system generator is made of titanium alloy and PVC material, which can easily combine the generator with the control device, and is made of corrosion-resistant and high-temperature resistant materials. The reactor is made of a corrosion-resistant new type and equipped with a safety relief valve to effectively prevent equipment damage caused by system failure and misoperation of the metering pump. The reactor adopts a two-stage reaction, and the conversion rate of the main raw material NaCLO3 is not less than 85%.

The reactor is equipped with an automatic electric heating device, which can automatically control the resistance value of the electric heater and adjust the heating amount through temperature detection signals to maintain a constant reaction temperature and achieve optimal conversion rate of the raw materials. Can automatically handle residual liquid without secondary pollution. Automatic operation: The equipment can achieve automatic operation except for necessary addition of chemicals. The regulating device is equipped with two high-precision electromagnetic metering pumps for the addition of NaClO and HCL, which will maintain high precision and accuracy of the injection amount. Adopting a Milton Roy metering pump. It has good corrosion resistance, metering, and automatic emptying function. No need for manual emptying and pumping, effectively reducing labor intensity. Inject valve to avoid buffer siphon. The liquid level control function can automatically stop the pump in case of material shortage. The negative pressure generated by the water jet will keep the pressure of the reactor and buffer at a lower vacuum pressure. Any pressure loss caused by any reason within the system (such as sudden water outage) will automatically shut down the system. And issue corresponding sound and light alarms. The water injector consists of a spring, diaphragm, and valve seat, which can automatically close after back pressure is applied and the pipeline is blocked, preventing pressure water from flowing into the reactor without the need for an additional check valve. Control panel and control system functions: Temperature control meter: accurately and effectively displays and controls the reaction temperature, enabling the equipment to achieve a high conversion rate. Power indicator light: lights up when powered on, low raw material level indicator light: lights up when raw material is exhausted. Feeding light: It lights up when the switch is turned to the Refill position. Buzzer, alarm in case of malfunction or shortage of materials. The negative pressure generated by the water injector during water injection is transmitted to the buffer through a plastic tube and then reaches the reaction chamber.

The raw materials are injected into the reaction chamber by a high-precision metering pump, and after sufficient reaction, CLO2 solution and a small amount of CL2 are produced. Maintain a certain working negative pressure in the buffer, at which point the system allows raw materials to enter the reaction chamber. Otherwise, the system will shut down and sound an alarm. Under negative pressure, the raw materials undergo sufficient reaction to produce disinfectant, which enters the buffer and is then dissolved in water through a water sprayer to reach the injection point. Local control cabinet: It is used for parameter acquisition, process control, interlock protection, alarm and other automated operations of the dosing and reaction system. It also has functions such as manual and automatic conversion, automatic temperature control, residual chlorine display, flow feedback, etc. It is equipped with RS485 interface and can remotely control the on/off of the device to achieve fault alarm The dosing system includes other necessary accessories such as relays, switches, ammeters, voltmeters, etc. The electrical control cabinet is equipped with complete facilities and components. And provide power cables and control cables inside the device, and connect and lay them. The dosing system includes other necessary accessories such as relays, switches, ammeters, voltmeters, etc. The electrical control cabinet is equipped with complete facilities and components. And provide power cables and control cables inside the device, connect and lay them, and seal the two ends of the connecting cables.

The price of customized chlorine dioxide generator

In winter, attention should be paid to antifreeze and necessary heating measures should be taken to avoid damaging equipment and dosing pipelines. The equipment room should be dry, dark, and well ventilated. Smoking and open flames are strictly prohibited in the workplace. When cleaning equipment, attention should be paid to the electrical control part to prevent electric shock. The metering pump, feeding pipe, and water sprayer are prone to blockage in the presence of impurities in the raw materials and water. Attention should be paid to cleaning and dredging, and sediment in the raw material tank should be regularly cleaned. The exterior of the raw material tank is equipped with a filter, and after a period of use, attention should be paid to flushing. The equipment casing is made of PVC plastic, and collision, compression, and sun exposure are prohibited.
