Yuequan Stainless Steel Precision Casting VP Series Deep Well Pump Hot Water Pump adopts patented precision casting integrated casting technology and CNC precision machining to carefully select reliable materials for each component. Even under very harsh operating conditions, it can achieve maximum durability and reliability, and can work continuously without faults for a long time. The impeller is precision cast from food grade stainless steel (AISI304/AISI316), which has strong sand and wear resistance. Thanks to advanced design, the efficiency of the water pump is greatly improved. Can be paired with EBARA Japan's Ebara motor and Franklin shielded motor from the United States for the production of in pipe pumps, with excellent noise reduction effect

Application of precision casting deep well pump:

·Suitable for deep wells, hot water wells, and ocean water lifting;

·Suitable for lifting water from rivers, reservoirs, canals, etc;

·Suitable for farmland irrigation and water use for humans and livestock in high-altitude mountainous areas;

·Suitable for water supply and drainage in cities, factories, railways, mines, and construction sites;

·Suitable for deep well pumps, fountain pumps, hot spring pumps, in pipe pumps, etc

·Can be combined with EBARA Japan's Ebara Electric and Franklin Electric from the United States to form the best hydrodynamic system

Characteristics of precision casting deep well pump:

1The maximum sediment concentration reaches 200g/m³

2The maximum temperature resistance can reach 90℃

3. Made of food grade SUS304 (SUS316L) precision casting, it has excellent strength and durability

4. The noise during operation is much lower than that of a typical stamping pump body, with excellent noise reduction effect, especially suitable for in pipe pumps

5. The water machine connection seat is NEMA standard, combined with American Franklin, EBARA, Japanese Ebara motors, etc., for better results

6. There are various installation methods available, both vertical and horizontal

Stainless steel precision cast deep well pump structure of 6 inches or morecharacteristic:

·The impeller, diffuser, top bracket, and bottom bracket are all made of cast stainless steel

·One piece molding patent stainless steel impeller, professional casting process can maximize the overall integrity and toughness of product structure

·Using CNC precision machining,Capable of a height tolerance of up to 0.55mm, concentric without deviation

·The smooth surface of the produced components provides high hydraulic performance and excellent appearance

·The special materials for the top bearing, middle bearing, and neck ring provide maximum sand handling capacity

Patent integrated stainless steel impeller

Integrated molding has excellent wear resistance and no disadvantages such as easy detachment of stamped impellers; Effectively reducing waterway resistance, ensuring smooth and efficient water flow

The integrated impeller is balanced and calibrated by a precision microcomputer balancing machine, and the impeller is concentric without deviation, which can effectively reduce the vibration generated during pump operation, relatively improve the stability of the pump motor, avoid motor bearing wear caused by vibration, and extend the service life of the pump motor.

Optional motor for precision casting deep well pump body:

1. Water shielded motor (EBARA Japan Ebara deep well motor tank motor/Franklin submersible motor/Taiwan shielded motor/Yuequan shielded motor)

It can be directly connected to the pump body for use, without the need for water or oil injection, with food grade hygiene and durability, making it the best choice for domestic water pumps.

The EBARA raw water shielded motor is the latest generation of safety and hygiene grade motors, which is easy to use. It adopts a water lubrication design, and the filling liquid uses propylene glycol aqueous solution. It not only lubricates the bearings, but also has the functions of rust prevention of internal parts of the motor, prevention of freezing during storage, and heat dissipation inside the motor to avoid local heating.

In addition, propylene glycol can also be used as a food additive and is a safety product to avoid water pollution. The power cord and connector are specially designed with high water resistance and durability in an integrated form, which does not require special maintenance, is not easily deformed or broken, and has excellent electrical performance.

The outer tube of the stator is welded with stainless steel and lined with stainless steel. It is sealed with epoxy resin to provide good insulation effect. Corrosion resistance, fast heat dissipation, and resistance to deep water pressure, with a working diving depth of up to 300 meters, it can be used for various submersible pumps to provide the best power in water.

2. Water filled motor (Taiwan water line motor/Yuequan water filled motor)

Fill the production tank with water, otherwise it may cause the motor to burn out. Water lubrication and cooling are repairable and cost-effective.

Internally, it uses food grade lubricating oil and high-performance ball bearings. Its sturdy center ball bearing ensures smooth and durable operation. Adopting enameled wire rewinding winding and detachable waterproof power connector, it has excellent electrical performance, high efficiency, and repairability. Stainless steel outer tube, corrosion-resistant, fast heat dissipation, resistant to deep water pressure, with a working diving depth of up to 300 meters, suitable for various submersible pumps to provide the best power in water.
