SHH-E fully automatic high-speed corrugated box pre folding hook bottom pasting machine
SHH-E fully automatic high-speed corrugated box pre folding hook bottom pasting machine
Product details
SHH-E fully automatic high-speed corrugated box pre folding hook bottom pasting machine
SFG-1200E
| Type of paper box | A maximum | A minimum | B maximum | B minimum | C最小 | D minimum | F minimum |
| Ordinary box | 700mm | 70mm | 840mm | 130mm | 8mm | 70mm | 51mm |
| bottom hook box | 700mm | 160mm | 790mm | 180mm | 9mm | 90mm | 85mm |
SFG-1400E
| Type of paper box | A maximum | A minimum | B maximum | B minimum | C最小 | D minimum | F minimum |
| Ordinary box | 700mm | 70mm | 840mm | 180mm | 8mm | 70mm | 51mm |
| bottom hook box | 700mm | 160mm | 790mm | 190mm | 9mm | 90mm | 85mm |
SFG-1600E
| Type of paper box | A maximum | A minimum | B maximum | B minimum | C最小 | D minimum | F minimum |
| Ordinary box | 700mm | 70mm | 1200mm | 130mm | 8mm | 70mm | 51mm |
| bottom hook box | 700mm | 160mm | 1100mm | 180mm | 9mm | 90mm | 85mm |
Technical Specifications:
| Linear velocity | Continuous adjustable from 0 to 220m/min |
| Suitable for paper | 220-800g/m ² cardboard, E-corrugated |
| Basic form of paste box | The first and third lines of the box are pre folded, polished, and glued to form a shape |
| Paper feeding method | Automatic continuous paper feeding |
| Use adhesive | Solute type |
| Required electricity | AC380、7.5KW |
| Weight | 2500kg |
| External dimensions | 10300mm×1000(1300)mm×1350mm |
| Counting range | 0-999999 (fully automatic counting) |
