Research grade inverted biological microscope ZXS-1400
Mechanical mobile ruler, with a stroke of 120x78mm, can easily hold various standard cell culture plates
Product details
Mechanical moving ruler
Mechanical mobile ruler, with a stroke of 120x78mm, can easily hold various standard cell culture plates. By using relevant platform attachments, a mobile ruler can be used to move culture dishes, culture bottles, slices, etc.
Mechanical moving ruler
Mechanical mobile ruler, with a stroke of 120x78mm, can easily hold various standard cell culture plates. By using relevant platform attachments, a mobile ruler can be used to move culture dishes, culture bottles, slices, etc.
Two lighting systems are available for selection
6V30W halogen lamp lighting, with two options: critical lighting or cola lighting. The critical lighting mode is a fixed bracket with a predetermined center of the filament; Equipped with an aperture stop, the spotlight can be rotated down. The Kola lighting mode is a rotating bracket, and the spotlight group can move out of the light path. The center of the filament is adjustable, with a field stop and aperture stop.
Phase contrast accessories
By selecting the matching phase contrast insertion plate based on the selected lighting fixture and combining it with the phase contrast objective lens, the phase contrast observation method can be achieved. The image contrast is better than that of bright field observation, and the cell imaging has a relief feeling, which can provide more detailed observation of some colorless and transparent cell tissues.
Standard Configuration
optical system |
Infinite color difference correction system |
Mirror body |
45 ° tilt, hinged binocular lens body, pupillary distance adjustment: 54mm-75mm, low hand position coarse fine adjustment coaxial, coarse adjustment stroke 9mm, fine adjustment accuracy 0.002mm, elastic adjustment device and upper limit device. Reservation center, adaptive wide voltage 100V-240V, continuously adjustable brightness, optional Kola lighting and critical lighting |
45 ° tilt, hinged tripod body, pupil distance adjustment: 54mm-75mm, low hand position coarse fine adjustment coaxial, coarse adjustment stroke 9mm, fine adjustment accuracy 0.002mm, elastic adjustment device and upper limit device. Reservation center, adaptive wide voltage 100V-240V, continuously adjustable brightness, optional Kola lighting and critical lighting | |
eyepiece |
High eye point, large field of view, flat field eyepiece PL10X/22mm, can be equipped with a micrometer |
High eye point, large field of view, flat field eyepiece PL15X/16mm | |
objective lens |
Infinite flat field achromatic objective lens (4X, 10X, 20X, 40X, 60X) |
Infinite flat field phase contrast objective lens (10X, 20X, 40X) | |
Carrier platform |
250mm × 160mm fixed loading platform, with mechanical movable ruler (movement range: 120mm × 78mm), loading platform extension plate, glass slide holder, Φ 35 skin culture dish holder, Teraseki holder, waist shaped hole metal loading platform, glass loading platform |
condenser |
Long working distance detachable spotlight group, numerical aperture N.A.0.3, optional Korla illumination and critical illumination |
Transmissive lighting system |
Critical lighting, 6V30W halogen lamp, predetermined center, continuously adjustable brightness, with variable aperture stop |
Kola lighting, 6V30W halogen lamp, predetermined center, continuously adjustable brightness, with variable aperture stop and field stop | |
Photography and videography accessories |
0.35X/0.5X/0.65X/1X CTV, C-type interface, adjustable focus |
other |
Color temperature transition/green contrast/yellow/neutral color filter (Φ 45), attenuation filter ND25/ND50, phase contrast plug group |
