Product Name: MotorolaMC70 Handheld Mobile Data Terminal

Product Description: How to Translate

The Motorola MC70 handheld data terminal utilizes the first durable enterprise digital assistant to integrate mobile phones PDA、 The functions of computers, scanners, and imaging devices are provided to mobile personnel. Can withstand being used in almost any usage environment throughout the day The Motorola MC70 handheld data terminal is designed to be compact and durable, providing true wireless WAN/LAN/PAN voice and data communication anytime, anywhere, including excellent voice functionality, data collection, and the ability to run almost any application.

Whether your mobile employees are in the warehouse, delivering goods, receiving goods at retail locations, or in hospitals, the MC70 handheld data terminal can provide them with everything they need to complete their tasks, achieving a new level of enterprise efficiency.

Product Features:
1. Compact, lightweight, sturdy and durable, it can be used in almost any environment all year round. It has passed the industry-leading double impact test (drop and roll), meets the IP54 sealing standard, and adopts an integrated antenna.

2．Intel? XScale PXA270 @ 624 Mh has multimedia performance similar to desktop computers, but with lower power requirements.

3．Microsoft? Windows Mobile 5.0 Premium or Phone Edition integrates multimedia and permanent memory.

4. Voice and high-speed wireless data in the GSM-EDGE and CDMA-EVDO revision 0 compatibility.

5. WLAN: 802.11a/b/g triple mode radio; Comprehensive VoIP support provides economical voice and data connectivity in the office.

WPAN: Bluetooth version 1.2, Class II includes wireless modems, print synchronization, and more.

7. High quality hands-free phones, microphones, and sensors provide first-class sound quality and sound effects.

8. Advanced onboard data acquisition: 1D and 2D barcode scanning, ranging from almost contact to 55 inches/139.7 centimeters away. Automated and error resistant data collection can increase work efficiency.

The 9.3.5-inch QVGA color screen can be easily viewed under any lighting conditions.

10. Multiple keyboard options: QWERTY or numeric options to meet the needs of different users and applications.

11. Supports standard and expansion cards to provide additional memory and expandable functionality.

12. Multiple battery options: Standard and large capacity sufficient power can meet full shift use in almost any environment.

Physical parameters:

Notification method: vibrator, LED indicator

扩展槽： SDIO

Network connection: Ethernet (via communication dock), full speed USB, host or client

Durable and sturdy: available

Audio options: Receiver, software support for full duplex recording and playback (stereo), headphone jack

Size: 6 x 3.1 x 1.5 inches (15.3 x 7.6 x 3.7 centimeters); DCDMA/EVDO revised version 0 configuration: 6 x 3.1 x 1.7 inches (15.3 x 7.9 x 4.4 cm) height x width x thickness

Keyboard: 26 numeric keys; 44 QWERTY keys

Display resolution: 3.5-inch QVGA, 65K colors, 240 x 320 (width x length)

Weight: LAN/PAN configuration: 11.2 ounces (314 grams); WAN/LAN/PAN configuration: 12 ounces (336 grams); CDMA/EVDO Revision 0 Configuration: 14.1 oz (400 g)

Display screen type: LED backlight, touch screen, TFT-LCD

2D imaging engine:

Front focal length of engine: Near focus: 5 inches; Far focus: 9 inches

照度环境 (LED)：635 nm +/- 20 nm

Left and right swing tolerance: deviation from normal+/-50 °

Forward and backward swing: deviation from normal position+/-65 °; Deviation from normal position+/-60 °

Light resistance: from full darkness to 9000 foot candles (96900 Lux)

Optical resolution (grayscale): 640 H x 480 V pixels (grayscale)

Field of view: Horizontal -32.2 °; Vertical -24.5 °

Rotation: Deviation from vertical by+/-35 °; 360°

Focusing Environment (VLD): 650 nm+/-5 nm

Linear one-dimensional scanner:

Optical resolution: -0.004 inches minimum element width

Scanning angle: 47 °+/-3 ° (default); 35 °+/-3 ° (reduction code)

Wireless data communication:

Voice Communication: Integrated IP voice communication support (P2P, PBX, and PTT), Wi Fi authentication, IEEE 802.11a/b/g direct sequence spread spectrum wireless LAN.

安全性： WPA2； WEP（40 或 128 位）； TKIP； TLS； TTLS（MS-CHAP）； TTLS（MS-CHAP v2）； TTLS（CHAP）； TTLS-MD5； TTLS-PAP； PEAP-TLS； PEAP（MS-CHAP v2）； AES； LEAP

Working channels: Channels 1-13 (2412-2472 MHz), Channel 14 (2484 MHz) limited to Japan, Channels 8-169 (5040-5845 MHz)

WLAN： 826

WPAN (supporting Bluetooth technology): Bluetooth version 1.2 with BT Explorer

Antenna: Built in antenna for LAN; External antenna for WAN

WWAN：GSM/EDGE（850、900、1800 和1900 MHz）, CDMA-EVDO

WPAN (supporting Bluetooth technology): Bluetooth version 1.2 with BT Explorer

Supported individual data rates: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

Power:

Extended capacity battery: Rechargeable lithium-ion smart battery 3.7V, 3800 mAh

Backup battery: Nickel hydrogen rechargeable battery, 20 mAh, 1.2 V, 1 battery

Main battery: Rechargeable lithium-ion smart battery 3.7V; 1900mAh smart battery

According to regulations:

RF exposure: 7887877892835

Laser safety: EN 60825-1, IEC 60825-1, 21CFR1040.10

EMC：EN 301 489-1, EN 55022, EN 301 489-7, FCC 第 15 部分 B 小部分, ICES 003 B 级, EN 55024, EN 61000-3-3, EN 61000-3-2, EN 301 489-17, IEC 60601-1-2

电气安全： UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1

无线通讯： FCC Part 24, EN 300 440-1, EN 301 511, EN 300 440-2, FCC Part 22, EN 300 328

Environmental regulations: RoHS Directive 2002/95/EEC

Usage environment:

Environmental sealing: IP54

Storage temperature: -40 ° to 140 ° F (-40 ° to 60 ° C) (excluding battery)

Humidity: 95% (no condensation)

Electrostatic discharge (ESD):+/-15kV air discharge; +/-8kV direct discharge

Working temperature: 14 ° to 122 ° F (-10 ° to 50 ° C)

Drop specification: Within the working temperature range, drop from a height of 4 feet to a cement floor, with 6 drops per face (total of 6 faces); Fall from a height of 5 feet to a concrete floor at an ambient temperature of 73 ° F (23 ° C), with 2 drops per face (6 faces in total)

Rolling specification: 10001.6 feet (0.5 meters) Rolling test (2000 impacts)

Performance parameters:

Scanning rate: 104 (+/-12) scans per second (bidirectional)

External interface: RS232

Windows Mobile： 有

Environmental light: 10000 candlelight

Data Collection Options: 1D Linear Scanner, 2D Imager

内存 (Flash/RAM)：64 MB（RAM）/128 MB（ROM） 或 128 MB（RAM）/128 MB（ROM）

操作系统 (OS)：Microsoft Windows Mobile 5.0 Premium Phone Edition

Processor (CPU): Intel XScale 624 Mhz processor
