Inverted fluorescence microscope ZFM-880
Designed for observation of cell tissue culture, it can be used to observe the process of cell growth, tissue contour, and internal structure
Product details
Designed for observing cell tissue culture, it can be used to observe cell growth processes, tissue contours, and internal structures. Optional fluorescent accessories can observe spontaneous fluorescence phenomena in vivo, fluorescence transfection of biological cells, protein transfer, and other fluorescence phenomena.
1 . Professional fluorescence system
The new generation of infinite far-field half complex chromatic aberration professional fluorescent lens, with a large numerical aperture design, can excite samples with stronger brightness and high ultraviolet transmittance. The multi-layer broadband coating technology applied has significant effects in terms of band width and ultraviolet transmittance.
2 . High performance filter
Select high-performance fluorescent filters with high spectral transmittance and good spectral line cutoff depth and steepness. The filter has no color penetration phenomenon, high signal-to-noise ratio, and significantly improved fluorescence imaging contrast. The filter block adopts background noise elimination technology, presenting a high contrast between the image and the background during observation, achieving good observation effect with brightness to excite the sample.
3 . Mercury lamp power supply and control system
Equipped with a lamp chamber safety protection device, it automatically cuts off the circuit when the lamp chamber door is not closed, preventing the mercury lamp from accidentally starting and avoiding ultraviolet radiation.
Ultra high voltage direct current mercury lamp provides high brightness fluorescent illumination intensity. Ensure high stability, safety, and service life.
A brand new digital power control system with a usage time counter and current value display, helping users determine the usage status of mercury lamps.
4 . Filter block switching mechanism
You can choose two or three bands as needed. The two bands are independently switched, and the filter block is easy to replace; The three band integrated filter block group comes standard with three fluorescent channels and one bright field channel.
Parameter configuration:
optical system |
Infinite color difference correction system |
|
Mirror body |
45 ° tilt, hinged binocular lens body, pupillary distance adjustment: 54mm-75mm, low hand position coarse fine adjustment coaxial, coarse adjustment stroke 9mm, fine adjustment accuracy 0.002mm, elastic adjustment device and upper limit device. Reservation center, adaptive wide voltage 100V-240V, continuously adjustable brightness, optional Kola lighting and critical lighting |
|
45 ° tilt, hinged tripod body, pupil distance adjustment: 54mm-75mm, low hand position coarse fine adjustment coaxial, coarse adjustment stroke 9mm, fine adjustment accuracy 0.002mm, elastic adjustment device and upper limit device. Reservation center, adaptive wide voltage 100V-240V, continuously adjustable brightness, optional Kola lighting and critical lighting | ||
45 ° tilt, hinged tripod body, pupil distance adjustment: 54mm-75mm, low hand position coarse fine adjustment coaxial, coarse adjustment stroke 9mm, fine adjustment accuracy 0.002mm, elastic adjustment device and upper limit device. Four slots can simultaneously install three sets of fluorescent blocks, with a predetermined center, adaptive wide voltage of 100V-240V, continuously adjustable brightness, and optional Kola lighting and critical lighting | ||
eyepiece |
High eye point, large field of view, flat field eyepiece PLN10X/22mm, can be equipped with a micrometer |
|
High eye point, large field of view, flat field eyepiece PL15X/16mm | ||
objective lens |
Ultra long working distance infinite far flat field achromatic objective lens (4X, 10X, 20X, 40X, 60X) |
|
Long working distance flat field positive phase contrast objective lens (4X, 10X, 20X, 40X) | ||
Ultra long working distance infinite far flat field fluorescent objective lens (4X, 10X, 20X, 40X, 60X) | ||
Ultra long working distance infinitely far semi achromatic flat field phase contrast fluorescent objective lens (20X, 40X) | ||
stage |
250mm × 160mm fixed loading platform, with mechanical movable ruler (movement range: 120mm × 78mm), loading platform extension plate, glass slide holder, Φ 35 skin culture dish holder, Teraseki holder, waist shaped hole metal loading platform, glass loading platform |
|
condenser |
Long working distance detachable spotlight group, numerical aperture N.A.0.3, optional Korla illumination and critical illumination |
|
Transmissive lighting system |
Critical lighting, 6V30W halogen lamp, predetermined center, continuously adjustable brightness, with variable aperture stop |
|
Kola lighting, 6V30W halogen lamp, predetermined center, continuously adjustable brightness, with variable aperture stop and field stop |
||
Reflective fluorescence illumination |
XDRFA Kola Illumination Reflector Illuminator with Variable Field Aperture and Adjustable Center |
|
100W mercury lamp light box, with adjustable filament center and focal length. Equipped with a reflective mirror center and adjustable focal length | ||
Digital mercury lamp power box, input wide voltage 100-240VAC | ||
Imported OSRAM 100W DC mercury lamp | ||
Excitation block group: standard B/G/V/UV excitation blocks | ||
Photography and videography accessories |
0.35X/0.5X/0.65X/1X CTV, C-type interface, adjustable focus |
|
other |
Color temperature transition/green contrast/yellow/neutral color filter (Φ 45), attenuation filter ND25/ND50, phase contrast plug group |
|
