GG14A-100-Single Motor Linear Motor Module
This picture is for reference only. Please refer to the dimension drawing for shipping specifications. The picture is just for reference
Product details
This image is for reference only. Please refer to the dimension drawing for shipping specifications
The picture is just for the reference.Please check the actual dimensions on the drawing.
parameter configuration
Parameter configuration
Continuous thrust |
46N |
Peak thrust/Peak thrust |
151N |
Continuous Current |
3.0Arms |
Peak current/PeakCurrent |
12.0Arms |
VGuide guide rail |
THK (Japan) |
Feedback/Feedback |
Resolution: 0.1um/0.5um/1um grating/magnetic grating optional |
Accuracy/Accessories |
Magnetic grid: Repetitive accuracy:+5um, positioning accuracy (after compensation):+10um |
Grating: Repetitive accuracy: ± 2um, positioning accuracy (after compensation):+3um | |
Straightness/Straightness |
Soil 10um/500mm |
|
Travel distance (mm)/ Load (kg) |
100 |
300 |
500 |
800 |
1000 |
1500 |
2000 |
4000 |
Maximum speed (m/s) | ||||||||
5 |
0.5 |
0.7 |
0.9 |
1.1 |
1.2 |
1.5 |
1.7 |
2.4 |
10 |
0.25 |
0.38 |
0.5 |
0.6 |
0.7 |
0.8 |
0.9 |
1.3 |
Note: The maximum speed data is based on the test results of staying at both ends for 0.2 seconds and accelerating at 10m/s3.
Appearance, installation dimensions, and weight
Dimensions,installationg guide and weight of the stage
|
Schedule/March Project/Project |
120 |
180 |
240 |
300 |
360 |
420 |
480 |
540 |
600 |
660 |
|
Number of holes (N) Numberofmountinghole |
1 |
1 |
1 |
1 |
3 |
3 |
3 |
3 |
5 |
5 |
|
entire length Overalllength |
380 |
440 |
500 |
560 |
620 |
680 |
740 |
800 |
860 |
920 |
|
Standard module weight (KG) Standardmodulevekht(KG) |
8.1 |
8.7 |
9.3 |
9.9 |
10.5; |
11.1 |
11.7 |
12.3 |
12.9 |
13.5 |
|
Weight of sports body (KG) Weightofmovingbody(KG) |
2.4 |
|||||||||
|
Maximum travel of customized module (mm) GustommoduleMaxstroke |
4200 |
|||||||||
|
Schedule/March Project/Project |
720 |
780 |
840 |
900 |
960 |
1020 |
1080 |
1140 |
1200 |
1260 |
|
Number of holes (N) Numberofmountinghole |
5 |
7 |
7 |
7 |
7 |
9 |
9 |
9 |
9 |
|
|
entire length Overalllength |
980 |
1040 |
1100 |
1160 |
1220 |
1280 |
1340 |
1400 |
1460 |
1520 |
|
Standard module weight (KG) Standardmodulevekht(KG) |
14.1， |
14.7 |
15.3 |
15.9 |
16.5 |
17.1 |
17.7 |
18.3 |
18.9 |
19.5 |
|
Weight of sports body (KG) Weightofmovingbody(KG) |
2.4 |
|||||||||
|
Maximum travel of customized module (mm) GustommoduleMaxstroke |
4200 |
|||||||||
Note: Module length can be customized according to customer requirements
