Freedom EVOlyzer Fully Automated Enzyme Immunoassay Workstation
Freedom EVOlyzer is designed to meet the needs of various laboratories. It is suitable for small laboratories with small sample sizes but multiple tes
Product details
Set up for youThe professional ELISA fully automated experimental platform of Ji
Freedom EVOlyzer(Fully automatic enzyme immunoassay workstation) YesTecanThe enzyme immunoassay integrated machine developed by the company is a microporous plateELISAAutomated experiments provide a specialized platform and offer efficient, reliable, and accurate experimental results.Freedom EVOlyzerNot only can it improve work efficiency, but it can also meet the constantly changing needs of today's diagnostic laboratories.
Meet various laboratory needs
Freedom EVOlyzerIntended to meet the needs of various laboratories. It is suitable for small laboratories with small sample sizes but multiple testing items, as well as laboratories engaged in high-throughput screening of large amounts of samples but with relatively fixed experimental items.Freedom EVOlyzerRequirements for both high throughput and flexibility,Its open platform enablesELISAAll common steps of the experiment are automated, including sample allocation, sample pre dilution, pipetting, incubation, washing, interpretation, and automatic generation of experimental results. All of these automated operations ensure the safety of the operator.Freedom EVOlyzeraccord withIVD-D 98 / 79 / ECThe requirements.
New advantages
Freedom EVOlyzerMake your work safer, simpler, and more efficient-From identifying raw samples to inputting experimental results into the local laboratory information system-Fully automated process to improve the quality and efficiency of experimental work. In addition, long-term unmanned operation has saved a lot of manpower for the laboratory, allowing staff to focus on more important tasks.
Continuous injection function saves time
Freedom EVOlyzerTruly achieving continuous injection, when the previous batch of experimental specimens is added to the microplate, the new batch of experimental specimens can be immediately loaded onto the workbench to ensure processing flux. Therefore, the laboratory can quickly process newly added samples at any time.
Freedom EVOlyzer - Intuitive ELISA Processing
Freedom EVOlyzerEnsure optimal processing and analysis from start to finish through a series of functions!
1. Select the sample needle you need
Freedom EVOlyzerCan be installed with Teflon coatingTeflon ®Stainless steel fixed sampling needles or disposable conductive sampling needles, or both types of sampling needles can be installed simultaneously. You can choose the optimal configuration according to your experimental needs to achieve optimal sensitivity and minimal sample dragging. Both types of sampling needles are equipped with liquid level detection function.
2. Maintain traceability of all samples
Tecan PosID3 ™The barcode scanner can scan and track the barcodes of all samples, microplates, and reagents throughout the entire experimental process, providing comprehensive sample traceability records.
3. No need for manual board rotation
Intelligent mechanical manipulator arm（RoMa）All microplates can be moved toFreedom EVOlyzerDifferent processing areas.
4. Set incubator functions as needed
The microplate can be heated by two incubators, each equipped with six incubation positions. The incubator can be set to different temperatures and can be equipped with oscillation function. Each closed incubation position can independently control temperature to achieve optimal temperature distribution and avoid light incubation. In addition, the workbench can also accommodate two room temperature incubators, each equipped with six light shielded incubation positions.
5.Set the steps for washing and reading boards
HydroflexThe board washing unit can be set to board washing and strip washing modes, and can be used up to4Plant different washes. The inventory of liquid in the bottle is monitored by weight sensors.SunriseAt the end of each experiment, the enzyme-linked immunosorbent assay (ELISA) usesMagellanTMSoftware for result analysis; At the same time, the instrument can also be used to verify the liquid distribution during the experimental process.
Full process experimental guidance
Powerful software features simplify the processing process
Freedom EVOlution Software Run Control -be used forFreedom EVOlyzerThe software, based on an intuitive graphical user interface, guides you through every step of the operation. This software provides multiple language options and can be operated on a touch screen.
