Product Name: Continuous Rolling Vacuum Packaging Machine (PLC Computer Programming)

Runkang brand 1100 single sealed continuous vacuum packaging machine

Product Introduction:

This product is independently developed by the company, with advanced functions and high configuration

Low failure rate, achieving continuous operation for 10-24 hours.

Functional advantages:

·Waterproof design of electrical box

·PLC programming touch computer board

·Schneider, Omron, Chint brand electrical appliances

·Studio and countertop made of 8mm thick 304 steel plate

·Sealing pre pressure, bag mouth flattening during heating sealing

·Easy to replace water-cooled heating rods and heating strips

·Infrared anti pinch function for safer worker operation

·Gear sealing locator, sealing without deviation or displacement

·Tsinghua Ziguang reducer, wear-resistant, long service life

·304 stainless steel chain, rust free, non polluting

·Dachang solenoid valve, low failure rate

·Comprehensive fault detection and text based alarm

Customer selection (price varies according to vacuum pump):

Customer packaging site

Continuous rolling vacuum packaging machine warehouse

Loading and shipping site

Continuous rolling installation site

The studio is vertically elevated and controlled by Taiwanese ABS brakes, ensuring smooth operation and accurate positioning; Imported tracks and double pitch chains from the Netherlands, controlled by Schneider and Omron electrical appliances, with water-cooled heating rods for stability and reliability; Equipped with a German imported vacuum pump, it has fast pumping speed, good vacuum effect, and long service life.
BH-1100R conveyor belt vacuum packaging machine features:
1. The working room can be vertically raised and lowered, with stable and reliable performance, low fault rate, and stable vacuum and sealing quality.
2. Adopting Taiwan ABS brake system, each workstation is accurately and stably positioned, and there is no need to adjust the brake clearance for 1 million times.
3. The use of cast aluminum magnesium alloy in the working chamber does not deform, and the entire working chamber is made of machined surfaces, ensuring a tight fit with the worktable and stable sealing performance.
4. By using a 3mm conveyor belt imported from the Netherlands, the belt strength has been increased and the belt life has been extended. The water flushing pipeline can be used to flush the belt at any time, making it easy to clean.
5. Adopting a special form of shut-off valve, it has a long service life, smooth gas path, and improved vacuum degree.
6. The heating rod is water-cooled, with a more stable sealing temperature, good sealing quality, and a long service life for the heating element.
7. The control appliances use Schneider (French brand) and Omron (Japanese brand) to greatly improve the stability of the working program, and the electrical box is sealed and moisture-proof.
8. BH-1100D type: sealing length of 1.10 meters, maximum packaging bag of 460cm. The machine worktable has four adjustable angles of 0 degrees, 8 degrees, 16 degrees, and 24 degrees, suitable for packaging dry products, semi fluids, and fluids, increasing the packaging range.
9. Equipped with German imported vacuum pump, stable operation, fast pumping speed, high vacuum degree, and long service life.
10. Adopting double pitch stainless steel chains extends the service life.
11. The control system and working process have added protection settings.
