One Transmission

1. Hydrostatic driven continuously variable transmission

2. Controlled by an electronic multifunctional handle

II Cutting table:

1. No line spacing cutting table

2. The cutting table can be reversed to achieve safe start-up and clearing of blockages

III Feeding and cutting system:

1. Adopting a V-shaped double row cutter arrangement, the material flows backwards in a concentrated manner, and the cutting length is adjusted in two sections of 13mm and 23mm to meet the needs of different types of livestock.

2. The automatic sharpening program is easy to operate and does not require reversing the blade. Engine idle sharpening reduces power consumption.

4 Grain crusher and throwing components:

1. Automatic lubrication system is added to the bearings of key parts of the grain crusher and accelerator structure

2. The feeding drum can unload materials within a range of 210 degrees, and the unloading height can be adjusted.

1Using a multifunctional joystick to achieve one stick control, the joystick controls the operation of the full hydraulic system through an imported solenoid valve

2Driver's cabin

3Equipped with a secondary thrower

4. Grain crusher:

(1) Adopting circular roller compaction roller

5. Material chopper

(1) V-shaped blade arrangement

(2) Knife barrel scheme

(3) V24 knife barrel

(4) Transport shredded materials to the middle through V-shaped blade arrangement

Note: The parameters and instructions are subject to the actual product!
