structural characteristics

2.1 Classification of Cleanrooms: Vertical laminar flow, single-sided operation;

2.2 Filtration efficiency: The filters are all high-efficiency filters without partitions, with a filtration efficiency of 99.999% for particles with a diameter of 0.3 μ m;

2.3 Fans and filters can be replaced and repaired in front of the clean bench;

2.4 The box body is made of 1.2mm thick cold-rolled steel plate with surface electrostatic spraying, which enhances the structural strength and makes the entire device more stable;

2.5 The work area countertop is made of stainless steel material, which is beautiful and corrosion-resistant;

2.6 The workspace is designed to be surrounded by positive pressure on all four sides (left and right, rear, and bottom) to protect products;※ 2.7 The control panel adopts a touch switch, with buttons consisting of fan button, lighting button, purple key, power button, socket button, air volume reduction button, and air volume increase button, making it easy to operate; The display screen shows the wind speed of the fan, display time, and working time of the ultraviolet lamppassThe working time of the filter

；2.8 The front window of the cleanroom is a manual window made of 5mm thick tempered glass

Glass door - counterweight structure, flexible and convenient to open up and down, hovering at any height within the travel range;

※ 2.9 Interlocking function between UV lamp, fan, and fluorescent lamp, which means that when the fan and fluorescent lamp are working, the UV lamp cannot be turned on to protect the operator;

2.10 Delay of 5 seconds for the UV lamp to turn on, protecting the safety of operators;

※ 2.11 Set the safety height of the front window opening, and sound an alarm when it is below or above the safety height to ensure stable performance of the equipment during use;
