1.6Mpa Steam Water Mixing Humidifier
1. Large amount of spray, long-term use, no blockage, no leakage, less maintenance 2. Steam water mixing atomization, high humidification efficiency 3
Product details
|
Industry Applications
|
|||
| textile industry | Moisture control in textile factories to reduce static electricity and dust. | papermaking industry | Moisture control of paper to reduce static electricity and dust. |
| computer room | Humidity control and reduction of static electricity in computer rooms. | electronics industry | Humidity control and reduction of static electricity in semiconductor component factories, LCD factories, PCB factories, IC testing factories, etc. |
| spray coating industry | Humidity control in car painting and spraying factories to reduce static electricity and dust. | Plastics industry | Humidity control and reduction of static electricity in plastic injection molding plants and plastic product manufacturing plants. |
| Gunpowder industry | The production, loading, manufacturing, and storage of gunpowder reduce static electricity. | printing industry | Plastic printing, exquisite printing, special printing humidity control, and reducing static electricity. |
| laboratory | Inspection, testing, quality control, analysis, laboratory environment with constant humidity. | tobacco industry | Tobacco leaf moisture regain, tobacco processing, humidity control in production, and dust reduction. |
| HVAC industry | Central air conditioning humidification, computer room central air conditioning humidification and reduction of static electricity. | Fresh storage | Fruit and meat products are kept moist for preservation and storage. |
| food industry | Dry and dehydrated food regain moisture and preserve freshness. | planting industry | Humidity control for large-scale cultivation of mushrooms, flowers, tropical plants, and soilless cultivation. |
| animal husbandry | Large scale breeding of livestock, birds, insects, etc. for moisturizing and disinfection. | Artificial landscape | Tropical artificial rainforests, films, exhibitions, etc. imitate natural environment cloud and mist landscapes. |
|
working principle
A nozzle that operates on the principle of siphon vacuum generates a jet of compressed air when it is sprayed out at the front end of the nozzle. The air in the water pipeline is carried away by the jet and forms a negative pressure vacuum, which then attracts the water in the waterway to the nozzle outlet and mixes it with compressed air before spraying it out. Two types of fluids are mixed at the front end of the nozzle to produce ultrasonic oscillations up to 7MHz, which atomize into fine water mist particles. These water mist particles, with a large specific surface area, are sprayed into the air through the nozzle and undergo moist heat exchange with dry and hot air, achieving the goal of isentropic humidification of the air. The average particle size of atomization can reach 7.5um, and the main components are a humidification tank, a humidification nozzle, and an installation kit combination; |
| Product Name | Gerun Soda Mixing Humidifier | Main shell |
Polypropylene (PP) |
| Nozzle material | 316 stainless steel | Atomized particles | 5-10μm |
| water quality requirements | Recommended purified water | Air pressure | ≤2.5kg |
| Usage environment | 0---60°C | Water pressure | 0.1---2.0Bar |
|
Detailed configuration parameters
|
|||||
| model | Spray volume (L/h) | Gas consumption (m ³/min) | Spray distance (m) | Spray particles (microns) | Control area (㎡) |
| GR-0610-S1Mpa | 10L/h | 250m³/min | 5.8m | 5μm | 120㎡ |
| GR-0610-1.6Mpa | 8L/h | 180m³/min | 4.5m | 7μm | 80㎡ |
| GR-0610-1Mpa | 6L/h | 150m³/min | 3.5m | 10μm | 60㎡ |
|
The equipment meets various customer needs
|
|
| 1 | Large amount of spray, no blockage, no leakage and maintenance free after long-term use. |
| 2 | Steam water mixed atomization, high humidification efficiency. |
| 3 | Good atomization effect, atomization particle diameter 5-10 microns, easy to absorb |
| 4 | Long spraying distance, with a spraying distance of 4-6 meters and a large coverage area |
| 5 | Easy to install; No rust, strong corrosion resistance |
|
Detail DisplayDetails determine quality
|
|
|
pressure gauge
Using clear and visible pressure gauges with accurate numerical values |
|
|
316 stainless steel body
No rust, corrosion-resistant! |
|
Specially designed nozzle
Large amount of spray, no blockage, no leakage and maintenance free after long-term use; |
|
|
Spray effect display
|
|||
 Electronic Factory Humidification |
|||
